| Part Number | NWCLT5748R11R5KBF |
|---|---|
| Product Series | |
| Series Description | Rectangular Transmitter Inductive Wireless Charging Coil |
| Construction Type | Transmitter Coil, For Charging Designs |
| Operating Range (Including Temp. Rise) | -25°C ~ 85°C |
| Inductance (@ 100Khz) | 11.5µH ± 10% |
| Max Power | 5W |
| DCR | 60mΩ±% |
 | |
| Coils | 1 | Wire | 0.08*105 | Turns | 12 |
